Electrical Design, Assembly & Test

Current events, engineered.

From schematic to populated board to validated system — Fertile Mined delivers electrical design, assembly and test, and speaks fluent firmware while doing it.

A manufacturer of medical robotic systems handed us an impossible, space-restricted retrofit. We delivered a 3-axis / 2-head pick-and-place leveraging Faulhaber encoded DC micro-motors, optical position sensors and precision ball-screw actuators — with custom transition PCBs and FFC cabling for a compact solution.

For a high-power electrical drop-out client we designed an automated demonstration system: wireless PC communications, two motorized mechanisms, custom bracketing, power supply and management, and a custom PC GUI — a tour de force of cross-functional engineering.

At Fertile Mined, our engineers are experts in both hardware and software — which is exactly why our products work as a whole.

— Why FMI №9

Motion Control Precision Pick-&-Place Robotics

Capabilities

What we bring to the face of the rock.

PCB Design & Layout
Custom and transition PCBs engineered for compact, manufacturable, serviceable assemblies.
Power Supply & Management
From battery systems to managed rails — designed for real duty cycles and thermal reality.
Motor Control
PWM-modulated stepper systems, encoded DC micro-motors, optical sensing and precision actuation.
Cable & Interconnect
Hi-flex, FFC and FPC cable management for motion systems and tight enclosures.
Data Acquisition & Analysis
Instrumented systems that capture the signal and make sense of it.
Assembly & Board-Level Test
Bare-board and assembly-level testing, specializing in high frequency.

Point us at a discipline, or hand us the whole product. We fold in testing, DFM/DFA and documentation at every step.

PCB Design & LayoutBoard AssemblyHigh-FrequencyEMC / EMIPower ManagementPWM Stepper DriveEncoded DC Micro-MotorsOptical Position SensingHi-Flex FFC / FPCWireless PC CommsData AcquisitionBoard & Assembly Test
